Network cabinet

Network Cabinet-A2
Feature:
 Exquisite design with precise dimension and craftsmanship
 Toughened glass front door with silk-screened flower pattern, door border and steel rear door
  Blue Zinc Moungting Profiles,free of static;
   Adjustable feet and heavy duty castors are available at the same time
  Several lockable cable entry on top cover and bottom panel with adjustable sizes
  Optional plinth enables cabinet to stay in a fixed position, meeting requirements of under-base cable entry/ventilation and prevention
   Efficient cabinet baying kit(patent)
   Removable side panels, easy to install and maintain
  Around 1/2~2/3 of original assembled volume when flat pack.
 ■  Standard Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494;  PART1、DIN41494; PART7 Standard
 ■  Loading capacity Static loading: 800KG (with adjustable feet)
 ■  Degree of protection IP20
 ■  Main material SPCC cold rolled steel
Thickness: mounting profile: 2.0mm;
mounting angle: 1.5mm; others: 1.2mm
 ■  Surface finish Frame: degreasing, pickling, phosphoric, dip-coat primed,
powder coat Others: degreasing, pickling, phosphoric, powder coat

Model No.
Capacity ( U )
Width
(mm)
Depth
(mm)
Height
(mm)
Packing Dimension
W*D*H
Volume
(CBM)
A2.6618. ■■■
18
600
600
988
670*670*1028
0.4615
A2.6818. ■■■
800
670*870*1028
0.5992
A2.6018. ■■■
1000
670*1070*1028
0.7370
A2.6622. ■■■
22
600
600
1166
670*670*1196
0.5369
A2.6822. ■■■
800
670*870*1196
0.6971
A2.6022. ■■■
1000
670*1070*1196
0.8574
A2.6627. ■■■
27
600
600
1388
670*670*1418
0.6460
A2.6827. ■■■
800
670*870*1418
0.8266
A2.6027. ■■■
1000
670*1070*1418
1.0166
A2.6632. ■■■
32
600
600
1610
670*670*1640
0.7362
A2.6832. ■■■
800
670*870*1640
0.9560
A2.6032. ■■■
1000
670*1070*1640
1.1757
A2.6637. ■■■
37
600
600
1833
670*670*1863
0.8363
A2.6837. ■■■
800
670*870*1863
1.0859
A2.6037. ■■■
1000
670*1070*1863
1.3356
A2.6237. ■■■
1200
670*1270*1863
1.5852
A2.6642. ■■■
42
600
600
2055
670*670*2085
0.9360
A2.6842. ■■■
800
670*870*2085
1.2153
A2.6042. ■■■
1000
670*1070*2085
1.4947
A2.6242. ■■■
1200
670*1270*2085
1.7741
A2.8642. ■■■
800
600
870*670*2085
1.2513
A2.8842. ■■■
800
870*870*2085
1.5781
A2.8042. ■■■
1000
870*1070*2085
1.9409
A2.8242. ■■■
1200
870*1270*2085
2.3037
A2.6647. ■■■
47
600
600
2277
670*670*2307
1.0356
A2.6847. ■■■
800
670*870*2307
1.3448
A2.6047. ■■■
1000
670*1070*2307
1.6539
A2.6247. ■■■
1200
670*1270*2307
1.9630
A2.8647. ■■■
800
600
870*670*2307
1.3448
A2.8847. ■■■
800
870*870*2307
1.7462
A2.8047. ■■■
1000
870*1070*2307
2.0673
A2.8247. ■■■
1200
870*1270*2307
2.5490
