Wall mount cabinet

Wall Mounted Cabinet-WM
Feature:
   Welded frame, reliable structure;
   Standing or wall mounting installation
   Adjustable feet and heavy duty castors are optional
   Easy mounting installationpatent);
   19” standard installation
   Removable side panels, side locks optional;
   Knock out hole for entering cable on both of top cove and bottom panel;
   120mm fan available
   Turning angle of front door is over 180 degrees.
 ■  Standard Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494;  PART1、DIN41494; PART7 Standard
 ■  Loading capacity Static loading: 60KG
 ■  Degree of protection IP20
 ■  Main material SPCC cold rolled steel
Thickness: mounting profile: 1.5mm; others: 1.2mm
 ■  Surface finish Degreasing, phosphoric, powder coat

Model No.
Capacity
(U)
Width
(mm)
Depth
(mm)
Height
(mm)
Packing dimension
W*D*H
Volume
(CBM)
WM.6406.■■■■
6
600
450
368
670*520*430
0.1498
WM.6606.■■■■
600
670*670*430
0.1930
WM.6409.■■■■
9
600
450
501
670*520*560
0.1951
WM.6609.■■■■
600
670*670*560
0.2513
WM.6412.■■■■
12
600
450
635
670*520*695
0.2421
WM.6612.■■■■
600
670*670*695
0.3106
WM.6415.■■■■
15
600
450
769
670*520*830
0.2888
WM.6615.■■■■
600
670*670*830
0.3725
WM.6418.■■■■
18
600
450
901
670*520*960
0.3344
WM.6618.■■■■
600
670*670*960
0.4309
WM.6422.■■■■
22
600
450
1082
670*520*1140
0.3971
WM.6622.■■■■
600
670*670*1140
0.5117
WM.6427.■■■■
27
600
450
1304
670*520*1365
0.4755
WM.6627.■■■■
600
670*670*1365
0.6127
