Open Rack
Open Rack-OR
Feature:
■
M
odular design, easily assemble and disassemble for delivery, low-cost;
■
Various optional accessories according to requirements (cable management slot, removable working panel, etc.,).
■ Standard
Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494; PART1、DIN41494; PART7 Standard
■ Loading capacity
Static loading: 150KG
■ Main material
SPCC cold rolled steel
Thickness: Plinth and front beams: 2.0mm;
Front and bottom beams: 2.0mm; Pole: 1.5mm
■ Surface finish
Degreasing, phosphoric, powder coat
Model No.
Capacity
(U)
Width
(mm)
Depth
(mm)
Height
(mm)
Dimension
W*D*H
Volume
(CBM)
OR.6622.90
■
■
22
600
600
1119
670*150*1149
0.1155
OR.6632.90
■
■
32
600
600
1562
670*150*1592
0.1600
OR.6637.90
■
■
37
600
600
1785
670*150*1815
0.1824
OR.6642.90
■
■
42
600
600
2007
670*150*2037
0.2047
OR.6647.90
■
■
47
600
600
2230
670*150*2260
0.2271
