Network cabinet

Network Cabinet-A1
Feature:
■ Exquisite design with precise dimension and craftsmanship；
■  Steel front & rear door without hole；
■   Blue Zinc Moungting Profiles,free of static
■   Adjustable feet and heavy duty castors are available at the same time；
■  Several lockable cable entry on top cover and bottom panel with adjustable sizes；
■   Optional plinth enables cabinet to stay in a fixed position, meeting requirements of under-base cable entry/ventilation and prevention；
■   Efficient cabinet baying kit(patent)；
■  Removable side panels, easy to install and maintain；
■  Around 1/2~2/3 of original assembled volume when flat pack.
■  Standard Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494；  PART1、DIN41494; PART7 Standard
 ■  Loading capacity Static loading: 800KG (with adjustable feet)
 ■  Degree of protection IP20
 ■  Main material SPCC cold rolled steel
Thickness: mounting profile: 2.0mm;
mounting angle: 1.5mm; others: 1.2mm
 ■  Surface finish Degreasing, phosphoric, powder coat

Model No.
Capacity ( U )
Width
(mm)
Depth
(mm)
Height
(mm)
Packing Dimension
W*D*H
Volume
(CBM)
A1.6618. 90■■
18
600
600
988
670*670*1028
0.4615
A1.6818. 90■■
800
670*870*1028
0.5992
A1.6018. 90■■
1000
670*1070*1028
0.7370
A1.6622. 90■■
22
600
600
1166
670*670*1196
0.5369
A1.6822. 90■■
800
670*870*1196
0.6971
A1.6022. 90■■
1000
670*1070*1196
0.8574
A1.6627. 90■■
27
600
600
1388
670*670*1418
0.6460
A1.6827. 90■■
800
670*870*1418
0.8266
A1.6027. 90■■
1000
670*1070*1418
1.0166
A1.6632. 90■■
32
600
600
1610
670*670*1640
0.7362
A1.6832. 90■■
800
670*870*1640
0.9560
A1.6032. 90■■
1000
670*1070*1640
1.1757
A1.6637. 90■■
37
600
600
1833
670*670*1863
0.8363
A1.6837. 90■■
800
670*870*1863
1.0859
A1.6037. 90■■
1000
670*1070*1863
1.3356
A1.6237. 90■■
1200
670*1270*1863
1.5852
A1.6642. 90■■
42
600
600
2055
670*670*2085
0.9360
A1.6842. 90■■
800
670*870*2085
1.2153
A1.6042. 90■■
1000
670*1070*2085
1.4947
A1.6242. 90■■
1200
670*1270*2085
1.7741
A1.8642. 90■■
800
600
870*670*2085
1.2513
A1.8842. 90■■
800
870*870*2085
1.5781
A1.8042. 90■■
1000
870*1070*2085
1.9409
A1.8242. 90■■
1200
870*1270*2085
2.3037
A1.6647. 90■■
47
600
600
2277
670*670*2307
1.0356
A1.6847. 90■■
800
670*870*2307
1.3448
A1.6047. 90■■
1000
670*1070*2307
1.6539
A1.6247. 90■■
1200
670*1270*2307
1.9630
A1.8647. 90■■
800
600
870*670*2307
1.3448
A1.8847. 90■■
800
870*870*2307
1.7462
A1.8047. 90■■
1000
870*1070*2307
2.0673
A1.8247. 90■■
1200
870*1270*2307
2.5490
