Wall mount cabinet

Wall Mounted Cabinet-ZH
Feature:
■ Double section welded frame structure;
■ Easy operation and maintaining at the back;
■ 19” standard installation;
■ Removable side panels, side locks are optional, easy installing and maintaining;
■ Knock out hole for entering cable on both of top cover and bottom panel;
■ 120mm fan (optional);
■ Turning angle of front door is above 180 degrees;
■ Turning angle of rear door is above 90 degrees.
 ■  Standard Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494;  PART1、DIN41494; PART7 Standard
 ■  Loading capacity Static loading: 60KG
 ■  Degree of protection IP20
 ■  Main material SPCC cold rolled steel
Thickness: mounting profile: 1.5mm; others: 1.2mm
 ■  Surface finish Degreasing, phosphoric, powder coat

Model No.
Capacity
(U)
Width
(mm)
Depth
(mm)
Height
(mm)
Packing Dimension
W*D*H
Volume
(CBM)
ZH.6406.■■■■
6
600
550
368
670*620*430
0.1786
ZH.6409.■■■■
9
501
670*620*560
0.2326
ZH.6412.■■■■
12
635
670*620*695
0.2887
ZH.6415.■■■■
15
769
670*620*830
0.3447
ZH.6418.■■■■
18
901
670*620*960
0.3987
ZH.6422.■■■■
22
1082
670*620*1140
0.4736
ZH.6427.■■■■
27
1304
670*620*1365
0.5670
ZH.6606.■■■■
6
600
600
368
670*670*430
0.1930
ZH.6609.■■■■
9
501
670*670*560
0.2513
ZH.6612.■■■■
12
635
670*670*695
0.3106
ZH.6615.■■■■
15
769
670*670*830
0.3725
ZH.6618.■■■■
18
901
670*670*960
0.4309
ZH.6622.■■■■
22
1082
670*670*1140
0.5117
ZH.6627.■■■■
27
1304
670*670*1365
0.6127
