Industrial Control Cabinet
Industrial control cabinet-CB Compact Enclosure |
|
Feature:
■ Multi-folded periphery of the enclosure to avoid water and sundries entering into the inner enclosure;
■ Cold rolled steel welded frame with strong structure;
■ All-round polyurethane gasket in the door with good protection;
■ Molded door border with exquisite image and strong intensity;
■ Door can be open from left or right;
■ Door can be turned to 110 degrees with hinge, and 180 degrees with special hinge;
■ Adjustable mounting panel;
■ M8 earth pole is mounted on the body, door and the mounting panel;
■ Mounting hole drilled at the back of the enclosure, no need extra holes. |
■ Standard |
Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494; PART1、DIN41494; PART7 Standard |
■ Loading capacity |
Static loading: 1000KG |
■ Degree of protection |
IP20 |
■ Main material |
SPCC cold rolled steel
Thickness of Steel: mounting profile: 2.0mm; tray: 2.0mm;
mounting angle: 1.5mm; others: 1.2mm |
■ Surface finish |
Frame: degreasing, pickling, phosphoric, dip-coat primed,
powder coat Others: degreasing, pickling, phosphoric, powder coat |
Model No.
|
Width
(mm)
|
Depth
(mm)
|
Height
(mm)
|
Hole size(E*F)
(mm)
|
Packing Dimension
W*D*H
|
Volume
(CBM)
|
CB.1032.9■00
|
200
|
120
|
300
|
133x43
|
230*150*330
|
0.0114
|
CB.1035.9■00
|
200
|
155
|
300
|
133x43
|
230*185*330
|
0.0140
|
CB.1033..9■00
|
300
|
210
|
300
|
233x45
|
330*240*330
|
0.0261
|
CB.1034. 9■00
|
300
|
210
|
400
|
233x45
|
330*240*430
|
0.0341
|
CB.1030. 9■00
|
380
|
155
|
300
|
303x63
|
410*185*330
|
0.0250
|
CB.1031. 9■00
|
380
|
210
|
300
|
303x63
|
410*240*330
|
0.0325
|
CB.1380. 9■00
|
380
|
210
|
380
|
303x63
|
410*240*410
|
0.0403
|
CB.1038. 9■00
|
380
|
210
|
600
|
303x63
|
410*240*630
|
0.0620
|
CB.1338. 9■00
|
380
|
350
|
600
|
303x63
|
410*380*630
|
0.0982
|
CB.1045. 9■00
|
400
|
210
|
500
|
303x113
|
430*240*530
|
0.0547
|
CB.1046. 9■00
|
450
|
210
|
640
|
303x113
|
480*240*670
|
0.0772
|
CB.1050. 9■00
|
500
|
210
|
500
|
303x113
|
530*330*530
|
0.0927
|
CB.1056. 9■00
|
500
|
210
|
600
|
303x113
|
510*240*630
|
0.0801
|
CB.1057. 9■00
|
500
|
250
|
700
|
303x113
|
530*280*730
|
0.1083
|
CB.1350. 9■00
|
500
|
300
|
500
|
303x113
|
530*330*530
|
0.0927
|
CB.1039. 9■00
|
600
|
210
|
380
|
500x113
|
630*240*410
|
0.0620
|
CB.1060.9■00
|
600
|
210
|
600
|
500x113
|
630*240*630
|
0.0953
|
CB.1067.9■00
|
600
|
210
|
640
|
500x113
|
630*240*670
|
0.1013
|
CB.1076.9■00
|
600
|
210
|
760
|
500x113
|
630*240*790
|
0.1892
|
CB.1058.9■00
|
600
|
250
|
800
|
500x113
|
630*280*830
|
0.1464
|
CB.1090.9■00
|
600
|
250
|
1000
|
500x113
|
630*280*1030
|
0.1817
|
CB.1260.9■00
|
600
|
300
|
1200
|
500x113
|
630*330*1230
|
0.2557
|
CB.1339.9■00
|
600
|
350
|
380
|
500x113
|
630*380*410
|
0.0982
|
CB.1360.9■00
|
600
|
350
|
600
|
500x113
|
630*380*630
|
0.1508
|
CB.1376.9■00
|
600
|
350
|
760
|
500x113
|
630*380*790
|
0.1891
|
CB.1368.9■0
|
600
|
350
|
800
|
500x113
|
630*380*830
|
0.1987
|
CB.1077.9■00
|
760
|
210
|
760
|
500x113
|
790*240*790
|
0.1498
|
|
