| ◆ 承载 |
静载承重达1000KG. |
| ◆ 防护等级 |
按EN60529/IEC529,GB4208-93 标准达到IP55级. |
| ◆ 主要材料 |
SPCC优质冷轧钢板制作;
厚度:安装板2.5mm,前门及横撑条2.0mm,骨架和后板1.5mm,顶盖和底板1.2mm. |
| ◆ 表面处理 |
脱脂、磷化、静电喷塑.
|
| |
|
|
订购号
|
宽度
(mm)
|
深度
(mm)
|
高度
(mm)
|
包装尺寸
W*D*H
|
体积
(CBM)
|
|
CC.4418.9■■■X
|
400
|
400
|
1800
|
470*470*1830
|
0.4042
|
|
CC.4420.9■■■X
|
2000
|
470*470*2030
|
0.4484
|
|
CC.4422.9■■■X
|
2200
|
470*470*2230
|
0.4926
|
|
CC.6418.9■■■X
|
600
|
1800
|
670*470*1830
|
0.5762
|
|
CC.6420.9■■■X
|
2000
|
670*470*2030
|
0.6392
|
|
CC.6422.9■■■X
|
2200
|
670*470*2230
|
0.7022
|
|
CC.8418.9■■■X
|
800
|
1800
|
870*470*1830
|
0.7483
|
|
CC.8420.9■■■X
|
2000
|
870*470*2030
|
0.8301
|
|
CC.8422.9■■■X
|
2200
|
870*470*2230
|
0.9118
|
|
CC.0418.9■■■X
|
1000
|
1800
|
1070*470*1830
|
0.9203
|
|
CC.0420.9■■■X
|
2000
|
1070*470*2030
|
1.0209
|
|
CC.0422.9■■■X
|
2200
|
1070*470*2230
|
1.1215
|
|
CC.2418.9■■■X
|
1200
|
1800
|
1270*470*1830
|
1.0923
|
|
CC.2420.9■■■X
|
2000
|
1270*470*2030
|
1.2117
|
|
CC.2422.9■■■X
|
2200
|
1270*470*2230
|
1.3311
|
|
CC.4618.9■■■X
|
400
|
600
|
1800
|
470*670*1830
|
0.5762
|
|
CC.4620.9■■■X
|
2000
|
470*670*2030
|
0.6392
|
|
CC.4622.9■■■X
|
2200
|
470*670*2230
|
0.7022
|
|
CC.6618.9■■■X
|
600
|
1800
|
670*670*1830
|
0.8214
|
|
CC.6620.9■■■X
|
2000
|
670*670*2030
|
0.9112
|
|
CC.6622.9■■■X
|
2200
|
670*670*2230
|
1.0010
|
|
CC.8618.9■■■X
|
800
|
1800
|
870*670*1830
|
1.0668
|
|
CC.8620.9■■■X
|
2000
|
870*670*2030
|
1.1833
|
|
CC.8622.9■■■X
|
2200
|
870*670*2230
|
1.2999
|
|
CC.0618.9■■■X
|
1000
|
1800
|
1070*670*1830
|
1.3120
|
|
CC.0620.9■■■X
|
2000
|
1070*670*2030
|
1.4553
|
|
CC.0622.9■■■X
|
2200
|
1070*670*2230
|
1.5987
|
|
CC.2618.9■■■X
|
1200
|
1800
|
1270*670*1830
|
1.5571
|
|
CC.2620.9■■■X
|
2000
|
1270*670*2030
|
1.7273
|
|
CC.2622.9■■■X
|
2200
|
1270*670*2230
|
1.8975
|
|
CC.4818.9■■■X
|
400
|
800
|
1800
|
470*870*1830
|
0.7482
|
|
CC.4820.9■■■X
|
2000
|
470*870*2030
|
0.8300
|
|
CC.4822.9■■■X
|
2200
|
470*870*2230
|
0.9118
|
|
CC.6818.9■■■X
|
600
|
1800
|
670*870*1830
|
1.0667
|
|
CC.6820.9■■■X
|
2000
|
670*870*2030
|
1.1832
|
|
CC.6822.9■■■X
|
2200
|
670*870*2230
|
1.2998
|
|
CC.8818.9■■■X
|
800
|
1800
|
870*870*1830
|
1.3851
|
|
CC.8820.9■■■X
|
2000
|
870*870*2030
|
1.5365
|
|
CC.8822.9■■■X
|
2200
|
870*870*2230
|
1.6879
|
|
CC.0818.9■■■X
|
1000
|
1800
|
1070*870*1830
|
1.7035
|
|
CC.0820.9■■■X
|
2000
|
1070*870*2030
|
1.8897
|
|
CC.0822.9■■■X
|
2200
|
1070*870*2230
|
2.0760
|
|
CC.2818.9■■■X
|
1200
|
1800
|
1270*870*1830
|
2.0220
|
|
CC.2820.9■■■X
|
2000
|
1270*870*2030
|
2.2429
|
|
CC.2822.9■■■X
|
2200
|
1270*870*2230
|
2.4640
|
|
CC.4918.9■■■X
|
400
|
900
|
1800
|
470*-970*1830
|
0.8342
|
|
CC.4920.9■■■X
|
2000
|
470*970*2030
|
0.9254
|
|
CC.4922.9■■■X
|
2200
|
470*970*2230
|
1.0166
|
|
CC.6918.9■■■X
|
600
|
1800
|
670*970*1830
|
1.1893
|
|
CC.6920.9■■■X
|
2000
|
670*970*2030
|
1.3192
|
|
CC.6922.9■■■X
|
2200
|
670*970*2230
|
1.4492
|
|
CC.8918.9■■■X
|
800
|
1800
|
870*970*1830
|
1.5443
|
|
CC.8920.9■■■X
|
2000
|
870*970*2030
|
1.7131
|
|
CC.8922.9■■■X
|
2200
|
870*970*2230
|
1.8819
|
|
CC.0918.9■■■X
|
1000
|
1800
|
1070*970*1830
|
1.8994
|
|
CC.0920.9■■■X
|
2000
|
1070*970*2030
|
2.1069
|
|
CC.0922.9■■■X
|
2200
|
1070*970*2230
|
2.3145
|
|
CC.2918.9■■■X
|
1200
|
1800
|
1270*970*1830
|
2.2544
|
|
CC.2920.9■■■X
|
2000
|
1270*970*2030
|
2.5008
|
|
CC.2922.9■■■X
|
2200
|
1270*970*2230
|
2.7471
|
|
CC.4018.9■■■
|
400
|
1000
|
1800
|
470*1070*1830
|
0.9203
|
|
CC.4020.9■■■
|
2000
|
470*1070*2030
|
1.0208
|
|
CC.4022.9■■■
|
2200
|
470*1070*2230
|
1.1214
|
|
CC.6018.9■■■
|
600
|
1800
|
670*1070*1830
|
1.3119
|
|
CC.6020.9■■■
|
2000
|
670*1070*2030
|
1.4553
|
|
CC.6022.9■■■
|
2200
|
670*1070*2230
|
1.5986
|
|
CC.8018.9■■■X
|
800
|
1800
|
870*1070*1830
|
1.7035
|
|
CC.8020.9■■■X
|
2000
|
870*1070*2030
|
1.8897
|
|
CC.8022.9■■■X
|
2200
|
870*1070*2230
|
2.0759
|
|
CC.0018.9■■■X
|
1000
|
1800
|
1070*1070*1830
|
2.0952
|
|
CC.0020.9■■■X
|
2000
|
1070*1070*2030
|
2.3241
|
|
CC.0022.9■■■X
|
2200
|
1070*1070*2230
|
2.5531
|
|
CC.2018.9■■■X
|
1200
|
1800
|
1270*1070*1830
|
2.4868
|
|
CC.2020.9■■■X
|
2000
|
1270*1070*2030
|
2.7586
|
|
CC.2022.9■■■X
|
2200
|
1270*1070*2230
|
3.0303
|
标准配置：一套顶盖,一套底板,一套骨架,一套前门,一块后门,2跟横撑条,一块安装板,1只梅花扳手
CC控制柜（不带侧门）; 因控制柜规格型号较多,不能一一录入,欢迎来电咨询,谢谢!
订购号定义： CC.■■■■.■■00■ 安装板喷涂RAL2000PN，其余RAL7035BN
CC.■■■■.■■02■ 安装板喷涂RAL2000PN，其余RAL7032BN
